CATIA V5 - Different thickness in a single part of file





Assalamualaikum wbt.



A video showing how to do different thickness in a single part of file. The process start with a wireframe and surface, then divided by few portion. The important idea is, to create few geometrical sets so that it is divided into different portions. Then, In the part design workbench, thickness command is use to do thick to each of the splitted surfaces in the respective geometrical sets.

Wassalam.

Thanks.

Thanks to Mr Tasbirul Islam from Bangladesh and Prof Baharudin from MALAYSIA to include me in the conference paper for relating to this method. You can read it here. Thank you. Wasalam. (Update 21-12-2016)

http://www.matec-conferences.org/articles/matecconf/abs/2017/04/matecconf_aigev2017_01007/matecconf_aigev2017_01007.html


Wednesday, May 18, 2016

Poster sample for EMD 112

Assalamualaikum and good afternoon.

This is a poster's sample tips that can be used to describe your positive value of your product. This poster also explains the title and also the team members in the group. Logo is optional.

Sorry for the late post. Anyway I have explained this in our previous lectures (Catia photo studio)
 Good luck my fellow students!

Wassalam.



Wednesday, April 20, 2016

Sunday, April 17, 2016

A 2-minute CATIA V5 Photo Studio Easy Tools tutorial





EMD 112 USM

Due to internal error of PDF file on our class yesterday (18/4/2016), I have attached file for on your own exercise (Group A) and for today class (Group B). Thanks!.

5. Download file for Workshop (DMU Kinematics)(Excavator) (file updated with constrains 19/4/2016) - Click HERE

6. Download file for Workshop (Photo Studio)(DS-star.jpg, lampo.zip,RD-CAR.zip, saltnpepper.zip, shooting.zip) - Click HERE

*Credits to original owner of the file DickSham and DS.

Airbus DMU - Digital Mock Up

Thursday, April 7, 2016

Dji Inspire V1 by CATIA V5 (wireframe and Surface Modeling) Day 2

Assalamualaikum wbt,

Today, almost complete the Landing Gear for Inspire 1, almost. To be continue next day.










Wednesday, March 30, 2016

Dji Inspire V1 by CATIA V5 (wireframe and Surface Modeling) Day 1

Isometric view (Credit)

 Front View (Credit)
Top View (Credit)

Side View (Credit)









Thursday, February 4, 2016

Creating Airfoil by using VB





Do you always come to a point where how do i insert thousands of points into catia without inputing it one by one, and keep thinking there is no end and do i made mistake in my previous points?



Watch this video and learn how to create airfoil using Visual Basic.



*credit to School of Aerospace Engineering, USM. My workplace.
